Q22-XM and XP

General Specifications
Tc Points
Case Drawings

MODEL NO CONSTANT VOLTAGE

• Q22-U12-XP
• Q22-U24-XP
• Q22-U36-XP
• Q22-U48-XP

CONSTANT CURRENT

• Q22-U12-CYYYY-XZ
• Q22-U24-CYYYY-XZ
• Q22-U30-CYYYY-XZ
• Q22-U36-CYYYY-XZ
• Q22-U42-CYYYY-XZ
• Q22-U48-CYYYY-XZ
• Q22-U54-CYYYY-XZ

Take the Quantum leap in LED driver technology. Our Quantum product family offers high-efficiency power solutions for both indoor and outdoor lighting applications. The Q22-XM is a 25-Watt, Class 2, Single Output, Switch-mode, LED Driver, C/C or C/V, Mini Stud Mount Ballast Style case, with 4 +1 DC Dimming.
